Ag Aircraft Sales

johnston aircraft service, inc.

New Aircraft Available
THRUSH

710 GAL available with 1300, and 1350 SHP

550 GAL available with 944, 1050, 1173, and 1300 SHP

510 GAL available with 750, 800, and 944, SHP



710 THRUSH
660 in sky.jpg (913372 bytes)

HIGH PERFORMANCE LARGER CAPACITY
WITH 710 GALLON HOPPER

It features:
New and improved wing design


WB01570_.gif (184 bytes)Outer Wing Panels Attach to Center Section for Greater Strength  and Fatigue Life
WB01570_.gif (184 bytes)Ailerons Moved Outboard for Increased Roll Rate

IMPROVED AERODYNAMICS
IMPROVED VISIBILITY FROM THE COCKPIT
INCREASED GROUND CLEARANCE
IMPROVED EMPENNAGE FOR BETTER FLIGHT CONTROL

SPECIAL INFORMATION ON THE 710...........



WB01624_.gif (281 bytes)WB01624_.gif (281 bytes)WB01624_.gif (281 bytes)WB01624_.gif (281 bytes)WB01624_.gif (281 bytes)WB01624_.gif (281 bytes)WB01624_.gif (281 bytes)WB01624_.gif (281 bytes)WB01624_.gif (281 bytes)WB01624_.gif (281 bytes)WB01624_.gif (281 bytes)WB01624_.gif (281 bytes)WB01624_.gif (281 bytes)WB01624_.gif (281 bytes)WB01624_.gif (281 bytes)WB01624_.gif (281 bytes)WB01624_.gif (281 bytes)WB01624_.gif (281 bytes)


S2RT65/ 710 (1300 SHP) Turbo Thrush - 5 Blade High Performance Propeller, 710 gallon hopper, 54ft. wing span, 230 gallon fuel, BIG flaps, servos, fairings, spring steel gear, air conditioning, cabin heat, Shadin Fuel Flow, nav/strobe/inst/ landing lights, MVP50T Glass Panel, 3" stainless steel spray system, 3" left side load, electronic hopper level indicator, certified to 14150 lb and NO WING A.D.s.

New : Higher performance propeller, taller vertical fin and rudder, new front end sheet metal design, redesigned tail wheel assembly, larger vacuum bagged hopper, new paint scheme, and optional -67 engine with 1350 SHP!!

****PLUS****

 LONG LIFE WING  (26,000 HRS).



S2R-550 THRUSH



Available With PT6 or Garrett Engines

NEW S2RT45 OR 60 or 65/550 (1173/1050/1300 SHP) Turbo Thrush - 5 Blade Propeller

NEW S2RG10/550 (944 SHP) Turbo Thrush - 4 Blade Propeller

EQUIPPED WITH 550 gallon hopper, extended wings, 230 gallon fuel, aileron servos, wing root fairings, spring steel main gear, air conditioning, cabin heat, nav/strobe/inst. lights, MVP50T Glass Panel, 3" left side load, complete spray system..

 LONG LIFE WING SPAR CAPS

WITH NO WING A.D. NOTES!!!!!

S2RT34/510

Available With PT6 and Garrett  Engines

NEW S2RT34/510 (750 SHP) P2 Turbo Thrush - 4 Blade Propeller

NEW S2RT140/510 (868 SHP) P2+ Turbo Thrush - 4 Blade Propeller

NEW S2RG10/510 (944 SHP) Turbo Thrush - 4 Blade Propeller

ALL EQUIPPED  WITH 510 gallon hopper, extended wings, 230 gallon fuel, aileron servos, wing root fairings, air conditioning, cabin heat, nav/strobe/inst. lights, MVP50T Glass Panel, 3" left side load, complete spray system.

 LONG LIFE WING SPAR CAPS !!

WITH NO WING A.D.s!!!!

EXPERIENCED AIRCRAFT

yellow.TIF (292430 bytes)

PLEASE NOTE - WE CAN CONTAINERIZE AND EXPORT AIRCRAFT THROUGHOUT THE WORLD!!



**PIPER**



1976 PA 36 400 SUPER Brave((400HP) JAS  Conversion - 3957TT/ 60 since O/H IO 720 engine/ 60 since IRAN 3 Blade  Hartzell Prop: 275 gallon hopper, Agrinautics  pump and fan, dropped streamlined booms with CP nozzles and check valves, 2"left side load, 90 gal fuel, extended wings, new fuel cells, nav/strobe/instrument/landing and taxi and night lights, Wag Flagger GPS, Crophawk flow meter, automatic flagman, left entry step, pistol grip, good tires/glass and paint. Wings have 4040 hours remaining on spar caps.

REDUCED TO $185,000 or best reasonable offer





**AGCAT**



**AIR TRACTOR**

**CESSNA**

**WEATHERLY**



THRUSH WING REBUILD INFO

  We are Selling and Installing REINFORCED Thrush wing Leading Edge Skins.

Much TOUGHER than stock!!!!



We Sell and Install Thrush factory Spar Caps

We can increase your fuel capacity up to 230 gallons

* We have a set of  COMPLETELY REBUILT THRUSH WINGS FOR SALE.  They have NEW Spar Caps, Extensions, 230 gal fuel, Heavy Duty Leading Edge Skins and Ribs, Wing Tips, Primed and ready for paint!
